BC RACING RM TYPE COILOVERS
12-16 Scion FR-S
F-20-RM
BC Racing RM Series Coilovers for the 2012-2016 Scion FR-S (ZN6) use a mono-tube inverted damper in the front and rear of vehicles that use McPherson style OEM strut suspension. On vehicles that use front struts only, BC Racing provides an inverted front strut and then provides an upright BR Series damper for the rear. Inverted dampers are useful in decreasing unsprung weight by moving the greatest mass of the strut to the top where it connects to the sprung weight of the chassis, where weight can be more easily shaved.
The BC Racing RM Series Coilover System uses a much larger inverted piston shaft that can handle higher lateral loads for longer periods of time without fatigue. These higher lateral loads are only prevalent on McPherson style strut suspension, not on Double A-Arm vehicles.
Features
- Highly customizable
- Inverted mono-tube damper
- Linear piston and damping curve
- Height adjustment independent of spring compression
- 30-clicks of simultaneous compression/rebound adjustment
- Front camber plates standard on applicable kits
- Rear camber plates available for applicable kits
- Custom spring rates and Swift Springs compatible
- Custom valving or valving paired for custom spring rates
- 2 year warranty against manufacturing defects
- Fully rebuildable with replacement parts
Specifications
- Part Number F-20-RM
- Part Name RM Series Coilovers
- Vehicle 2012-2016 Scion FR-S
- Chassis Code ZN6
- Front Springs (kg/mm) 62-160-8kg
- Rear Springs (kg/mm) 62-160-8kg
- Front Swift Springs (kg/mm) 62-127-X
- Rear Swift Springs (kg/mm) 62-152-X
- Front Camber Plates Included
- Rear Camber Plates Not Applicable
BC Racing produces highly customizable coilover suspension systems for drivers who want to tune ride height, damping, and overall handling feel. Popular across street, autocross, and track-day builds, BC coilovers are known for value, broad application coverage, and the ability to tailor a setup to match comfort goals or competitive performance demands.
Add your collapsible row content here.
BC Racing RM Coilovers: Scion FR-S 2013 - 2016
- Unit price
- /per
PART # F-20-RM
F-20-RM BC Racing RM Type Coilovers 12-16 FR-S. BC Racing inverted RAM Type model includes all of the great features from the BR Type model, and then takes everything a notch higher By using an inverted coilover system.
